Model MS Helicopter Tow Cart
Lifting capacity: 9,000 lbs (4,082 kg)
$24,400
The Model MS helicopter tow cart is our midrange model, sitting between the lighter-duty Model E and the heavy-duty Model 4, part of our full range of helicopter tugs. With a 9,000 lb (4,082 kg) lifting capacity, a standard built-in ground power unit, and 6–8 hours of battery life, the Model MS is built to move mid-size helicopters safely and efficiently with a single operator. Like every Chopper Spotter, it’s made in the U.S.A. and designed to last for decades.
Ideal for charter operators, flight schools, and multi-aircraft fleets, the Model MS handles popular mid-size rotorcraft such as the Bell 407, Airbus H125 and H130, and Robinson R66.
An auxiliary power unit comes standard with the Model MS tow cart, along with dual casters capable of transporting heavier aircrafts with a more balanced weight distribution. The Model MS provides ease-of-use and safety for both the operator and helicopter with the help of our wireless handheld control system for optimal speed control.
The Chopper Spotter team is ready to work with you to tailor and modify our offerings to meet your unique helicopter towing needs. Contact us today for the safer, smarter solution to helicopter ground-handling.
Product Specs
The Model MS pairs a 9,000 lb hydraulic lifting capacity with four Optima AGM non-spillable batteries for 6–8 hours of continuous runtime, so it’s ready for back-to-back moves throughout a busy flight day without constant recharging. Its 1 hp DC motor, electric braking, and variable speed control up to 3 ft/s give operators smooth, precise handling of heavier aircraft.
A built-in auxiliary power unit (APU) comes standard, letting the Model MS double as a portable ground power unit to start your helicopter or run avionics on the ramp. Dual casters distribute weight evenly for added stability, while overload protection with an auto-reset 100-amp breaker and a grooved drive wheel keep movement controlled and dependable in demanding conditions.
- Price: $24,400
- Lifting capacity: 9,000 lbs (4,082 kg)
- Motor: 1 hp DC
- Batteries: 4 Optima AGM non-spillable
- Battery life: 6-8 hours
- Charger output: 24 V, 10 A
- Charger input: 117 V @ 60 Hz or 230 V @ 50-60 Hz
- APU: Standard
- LED spotlight: Optional
- Drive wheel: Grooved (8 in x 5 in) (20.3cm X 12.7cm)
- Casters: Dual
- Lifting system: Hydraulic
- Braking: Electric
- Speed control: Variable up to 3 ft/s (1 m/s)
- Overload protection: 100 amp breaker (auto reset)
- Color: Safety Yellow
- 2026 Brochure
- Ships worldwide in as little as 2–3 business days
How It’s Made
Made in the USA
Fast, Worldwide Shipping
Frequently Asked Questions
What helicopters can the Model MS Helicopter Tow Cart move?
With a 9,000 lb (4,082 kg) lifting capacity, the Model MS is suited to a wide range of mid-size helicopters, including popular models like the Bell 407, Airbus H125 and H130, and Robinson R66. If you’re unsure whether the Model MS is right for your aircraft, contact our team and we’ll help you confirm the best fit.
What’s the difference between the Model E, Model MS, and Model 4?
The Model E is our base model, with a 4,500 lb capacity for lighter helicopters. The Model MS is our midrange model, lifting up to 9,000 lbs with a standard ground power unit and longer battery life. The Model 4 is our heavy-duty flagship, moving helicopters up to 11,900 lbs. All three are remote-controlled, electric, and made in the U.S.A. Compare our full lineup of helicopter tugs and tow carts to find the right fit for your aircraft.
Does the Model MS come with a ground power unit?
Yes. A built-in auxiliary power unit (APU), also known as a ground power unit (GPU), comes standard on the Model MS, so you can start your helicopter or run avionics and equipment directly from the tow cart with an optional APU power cable.
Can the Model MS Helicopter Tow Cart be operated by one person?
Yes. Like every Chopper Spotter, the Model MS is designed for safe, single-operator use with a wireless handheld controller—no wing walker or extra crew required.
Can I get replacement parts for my helicopter tow cart?
Yes. We offer a wide range of new and used helicopter tug replacement parts so you can keep your Model MS running for years to come.
