Model E

Lifting capacity: 4,500 lbs (2,041 kg)

$12,712

The Model E is our base model product, serving as a highly capable and easy-to-use tool for moving lighter helicopters. With a lifting capacity of up to 4,500 pounds and the ability to add an auxiliary power unit and dual casters, the Model E combines safety and maneuverability with a smaller footprint, making it easy to store anywhere in your facility. For those in need of a reliable and streamlined method of moving their lighter aircraft, the Model E is the perfect solution, capable of being tailored to meet your exact specifications. Get yours today to start experiencing total on-the-ground control.

Request More Information

Product Specs

Product Specs Product Specs

  • Price: $12,712
  • Lifting capacity: 4,500 lbs (2,041 kg)
  • Motor: 1 hp DC
  • Batteries: 2 Optima AGM non-spillable
  • Battery life: 3-4 hours
  • Charger output: 24 V, 6 A
  • Charger input: 117 V @ 60 Hz or 230 V @ 50-60 Hz
  • APU: Optional
  • LED spotlight: Optional
  • Drive wheel: Grooved (8 in x 5 in) (20.32cm X 12.7cm)
  • Casters: Single (dual optional)
  • Lifting system: Hydraulic
  • Braking: Electric
  • Speed control: Variable up to 3 ft/s (1 m/s)
  • Overload protection: 100 amp breaker (auto reset)
  • Color: Safety Yellow

How It Works

Designed for Effortless Operation

The Chopper Spotter design connects to your helicopter at the skids, resulting in a much safer and more secure method of movement. See how it works in 7 easy steps to position your aircraft exactly as you need to – in even the toughest conditions.

See How It Works
